Gen 990 Photo

This is the photo of Gen 990 on the car. It shows you different colors depending on the angle where you look at

HEAT-ZERO Performance Data

Hello everyone.

I'm going to introduce HEAT-ZERO brand of Filink.

As I mentioned before, Filink has two kinds of Window film as 'GEN Auto' for Automotive, and 'HEAT-ZERO' for Commercial, and Residential.

I'll show you HEAT-ZERO performance data below.



                                                                                             Product Series name is sorted by first number of each product name.

For example, Heat H 05, 20, 35, 60 is 'H Series',  Heat R 80, 90 is 'R Series'





Heat E Series

Heat E series blocks 99% of UV and more than 70% of Infrared. This product is has good quality with reasonable price.

E 05, 20, 35 _  It is a Chip Dyed film with Black Color, but it is much durable against fade and corrode than competitors.

  E 60 _  It is 100% Nano Ceramic window film which is not allow any metal or dye with Blue Color. There is no electric wave obstacle or interference unlike metallic film.



Heat P Series

100% Nano Ceramic window film doesn't allow any metal or dye without electric wave obstacle or interference.

Heat P series is premium product which blocks 99% of UV as well as good rejection of Infrared at 781-2500nm with blue color.

P 90 _ more than 90% of IRR

P 80 _ more than 80% of IRR



Heat R Series

100% Nano Ceramic window film doesn't allow any metal or dye without electric wave obstacle or interference.

Heat R series is luxury product which blocks 99% of UV as well as good rejection of Infrared at 781-2500nm. At the same time, it has high clarity of high VLT with blue color.

R 90 _ more than 90% of IRR

R 80 _ more than 80% of IRR



Heat U Series

It is designated for a long time. It has high rejection of heat wiht Diamond color. Diamond color gives elegant and style to the film.

U 95 _ more than 95% of IRR

U 90 _ more than 90% of IRR



Heat Hybrid

Heat Hybrid is partially coated metal on the Nano Ceramic film. It has blue color and a little bit of glare, but it looks style and has good rejection of heat at the same time with reasonable price.



Heat ICE Hybrid

It has both benefit of Inorganic convergence and IR film through Nano Ceramic sputtering technology. The film is consist of 7 layer Coating with blue-gold color.



Heat Black Label

It is the most outstanding product among HEAT-ZERO.

.

.

Go to Automotive (GEN AUTO) Film.

Tint Terminology

MIL THICKNESS.

A thousandth of an inch is a derived unit of length. Equal to 0.001 inch, it is normally referred to as a thou, a thousandth, or (particularly in the United States) a mil.

PLY

A layer of material. Ply is used to display the number of separate layers of polyester film that are used in the manufacturing process to make a particular window tint product.

VISIBLE LIGHT TRANSMITTED (VLT)

The percentage of visible light (380 – 750nm) passes through a window or material.

When you choose the film, High VLT film has light color and high clarity. Otherwise, Low VLT film has Deep color like black and is hard to look inside of the car from outside.

VISIBLE LIGHT REFLECTED (VLR)

Visible light rejected is the total percentage of visible light reflected by a glazing system that can be seen visually.

Normally, metallic film has high VLR and it is glare.

SOLAR ENERGY ABSORBED

Solar energy absorbed is the ratio of the amount of total solar energy directly absorbed by the glazing system to the amount of total solar energy falling on that glazing system.

SOLAR ENERGY TRANSMITTED

Solar energy transmitted is the ratio of the total solar energy passing through the glazing system to the amount of total solar energy falling on that glazing system. The less solar energy transmitted through a glazing system, the less heat that enters.

SOLAR ENERGY REFLECTED
Solar energy reflected is the ratio of the amount of the total solar energy directly reflected by the glazing system.

SHADING COEFFICIENT (SC)
Shading coefficient, is a value that determines one type of thermal performance of a glass unit (panel or window) in a building. It is basically the ratio of solar gain (due to direct sunlight) passing through a glass unit to the solar energy which passes through 3mm Clear Float Glass. It is referred to as an indicator to how the glass is thermally insulating (shading) the interior when there is direct sunlight on the panel or window.

Briefly, low SC film is more effective when you are cooling down your place in summer.

TOTAL SOLAR ENERGY REJECTED (TSER)

Total solar energy rejected is the percentage of incident solar energy rejected by a glazing system.

It is one of the most important factors when you choose the window film. High TSER means good to reduce the heat.

U-VALUE U-value is a measure of the rate of heat conductivity of a glazing system. For example, low u-value film is effective when you warm your place in winter.

ULTRAVIOLET REJECTED (UVR)
Ultraviolet rejected is the ratio of ultraviolet solar energy (wavelength of 300 – 380nm) that is transmitted by a glazing system to the total solar ultraviolet energy falling on the glazing system.

EMISSIVITY (E) Emissivity is a measure of surface’s ability to absorb or reflect far-infrared radiation. Infrared radiation is that which is sensed by the body as heat.

SOLAR HEAT GAIN COEFFICIENT (SHGC)

Solar gain (also known as solar heat gain or passive solar gain) refers to the increase in temperature in a space, object or structure that results from solar radiation. The amount of solar gain increases with the strength of the sun, and with the ability of any intervening material to transmit or resist the radiation.

GEN Auto Performance Data



Hello Everyone, I'm going to introduce GEN Auto Film from Filink.

As you can see above, Filink has two kinds of Brand Which are GEN Auto, and HEAT-ZERO. GEN Auto film is for Automotive, and HEAT-ZERO film is for Commercial and Residential.

I'm going to show you performance data of  GEN Auto Film.

                                                                                            The product series will be sorted by first number of the product name.

For example, Gen 305, 320, 335, 360 is '3 Series', and GEN 780 is '7 Series'







1 Series

It is a 1 ply thin film. Indeed, it is easy to install, and has high clarity of VLT. Also it blocks more than 99% of UV. It is reasonable price.

3 Series & 5 Series' Black Color

It is Chip Dyed film. However, it has good durability, and doesn't need to worry about fade, or corrode. Also it blocks more than 99% of UV.

3 Series _ Blocking more than 70% of Infrared

5 Series _  Blocking more than 80% of Infrared

3 Series & 5 Series' Blue Color

As it is 100% Nano Ceramic Window film, it doesn't allow any dye or metal in the film. Therefore, No electric wave obstacle or interference will be affected when you are driving. It blocks more than 99% of UV,  has higher than 60% of VLT which means high clarity at the same time. It is a Premium film which reduces heat to block Infrared at 781-2500nm.

3 Series _  more than 70% of IRR

5 Series _   more than 80% of IRR

 7 Series

As it is 100% Nano Ceramic Window film, it doesn't allow any dye or metal in the film. Therefore, No electric wave obstacle or interference will be affected when you are driving. It blocks more than 99% of UV,  has higher than 70% of VLT which means high clarity at the same time. It is a Luxury product which blocks more than 80% of Infrared.

9 Series

It is made by Filink's own skill to be differentiated from competitors. 9 Series film rejects more than 95% of Infrared. It looks elegant and luxury with diamond color. It is the most valueable product among Filink product.

.

.

                                        Go to Architectural Performance( HEAT ZERO) Data

Filink Korea Nano Ceramic Window Film

Welcome Everyone.

Thank you for visiting Filink Korea Blogger.

Filink is manufacturing Nano Ceramic Window Film for Automotive, Residential, Commercial, and Safety.

Ceramic Window Film is good at blocking heat, and UV from Sun.

Some Filink products, and knowledge about Window Film will be introduced on the blogger.

We are happy to hear your idea, please feel free to share your idea.

If you have any questions, or inquiries, please contact to info@filink.kr.

Thank you.

Filink Co., Ltd.
